Floor Hinge NewNeo 8622 – 105Kg
Original price was: 820.000 VND.0 VNDCurrent price is: 0 VND.
Floor hinges are commonly used for glass doors in Vietnam, especially in office buildings, shops, and various types of retail stores. They feature a compact design and operate using a piston and hydraulic oil for lubrication and resistance control.
Out of stock
Floor hinges are widely used for glass doors in Vietnam, especially in office buildings, shops, and various commercial spaces. Featuring a compact design, they operate using a piston and hydraulic oil for lubrication and resistance control.
Advanced adjustment features—left-right, up-down, and height—make installation easier for technicians.
The hinge offers two closing speeds: the main closing speed and the final latch speed.
Commonly paired with tempered glass and patch fittings, floor hinges are also compatible with aluminum, steel, and wooden doors.
| Thương hiệu |
NEWNEO |
|---|---|
| Thương hiệu : |
Nhật Bản |
| Sản xuất : |
Thái Lan |
| Sử dụng : |
Dễ sử dụng , dễ lắp đặt, với mức giá hợp lý nhất trong dòng bàn lề sàn |
| Giá : |
Liên hệ |
- Material: SUS304 stainless steel, stainless steel cover
- Floor hinge dimensions: 308 × 108 × 42 mm
- Applicable door size: 1050 × 2400 mm
- Hold-open angle: 90°
- Maximum opening angle: 120°
- Note: Additional accessories required for installation
- Included Accessories
- 1 floor hinge
- 1 floor hinge cover
- Screws
- Floor box
